Numerical investigation of steel-timber composite beams with cold-formed omega girders. Part 2: Beams with modifications and reinforced beams
More details
Hide details
1
Faculty of Civil and Transport Engineering, Institute of Building Engineering, Poznan University of Technology, Poland
2
Department of Civil Engineering, Czestochowa University of Technology, Poland
3
Faculty of Civil and Environmental Engineering, West Pomeranian University of Technology in Szczecin, Poland
Submission date: 2024-08-20
Final revision date: 2024-11-04
Acceptance date: 2024-11-05
Publication date: 2025-12-01
Corresponding author
Marcin Chybiński
Faculty of Civil and Transport Engineering, Institute of Building Engineering, Poznan University of Technology, Piotrowo 5, 60-965, Poznań, Poland
Archives of Civil Engineering 2025;71(4):515-526
KEYWORDS
TOPICS
ABSTRACT
This paper is part 2 of a numerical investigation of steel-timber composite beams with cold-formed omega girders and laminated veneer lumber slabs. After conducting a preliminary analysis of the composite beam cross-section in part 1 of the paper, a modification to the cross-section and a reinforcing method were proposed in part 2. In order to increase the load-bearing capacity of the beam, modifications, such as placing a metal sheet inside of the girder or placing a channel outside of the girder, were proposed. These modifications can be made at the production stage of the steel girders. The modification in form of a channel placed outside the omega girder provided the highest increase in the load-bearing capacity. However, the mass of the modified beam with the channel was 29.6% greater than the mass of the reference beam, and the modifying the girder using channels poses a particular challenge. For this reason, the modifications in the form of a flat sheet can be used instead of the channel. The sheet metal may be located inside the omega section to increase the aesthetics of the beam. Furthermore, the effectiveness of the carbon fibre reinforced polymer tape was analysed as a method of beam reinforcement at the building operation stage. The use of the tape resulted in increased load-bearing capacity. However, the increase in the load-bearing capacity of the beam may be limited because of the yielding of the support zone.
